微信小程序蓝牙连接2.0说明:
1、本版本区分了ANDROID和IOS系统下蓝牙连接的不同方式。
2、兼容了更多情况下的链接包括
(1)未开启设备蓝牙,当监听到开启了蓝牙后自动开始连接。
(2)初始化蓝牙失败后每3000ms自动重新初始化蓝牙适配器。
(3)安卓端开启蓝牙适配器扫描失败,每3000ms自动重新开启。
(4)IOS端获取已连接蓝牙设备为空,每3000ms自动重新获取。
(5)安卓端蓝牙开始链接后中断扫描,连接失败了,重新开始扫描。
(6)IOS端开始连接设备后,停止获取已连接设备,连接失败自动重新开启获取。
(7)连接成功后,关闭系统蓝牙,蓝牙适配器重置。
(8)连接成功后,关闭系统蓝牙,再次打开蓝牙,自动重新开始连接。
(9)连接成功后,关闭目标蓝牙设备,自动重新开始扫描(获取)。
(10)连接成功后,最小化小程序(连接未中断),打开小程序显示已连接。
(11)连接成功后,杀掉小程序进程,连接关闭,自动重新开始扫描(获取)。
我的连接是在App.js中做的。在App.js中的onLaunch触发是调用 init()方法。
init代码:
init: function (n) { this .list = []; this .serviceId = "6E400001-B5A3-F393-E0A9-E50E24DCCA9E" ; this .serviceId_2 = "00001803-0000-1000-8000-00805F9B34FB" ; this .serviceId_3 = "00001814-0000-1000-8000-00805F9B34FB" ; this .serviceId_4 = "00001802-0000-1000-8000-00805F9B34FB" ; this .serviceId_5 = "00001804-0000-1000-8000-00805F9B34FB" ; this .serviceId_6 = "00001535-1212-EFDE-1523-785FEABCD123" ; this .characterId_write = "6E400042-B5A3-F393-E0A9-E50E24DCCA9E" ; this .characterId_read = "6E400012-B5A3-F393-E0A9-E50E24DCCA9E" ; this .connectDeviceIndex = 0; this .isGettingConnected = false ; this .isDiscovering = false ; this .isConnecting = false ; this .connectedDevice = {}; console.log( 'init state' , this .connectedDevice.state); if (! this .connectedDevice.state || n == 200) { this .connectedDevice.state = false ; this .connectedDevice.deviceId = '' ; this .adapterHasInit = false } this .startConnect(); } |
说明:
1、 serviceId_2~6 是我已知的想要连接的蓝牙设备的serviceId可以只写一个。
2、characterId_write 是我已知的想要连接的蓝牙设备写入数据的特征值。
3、characterId_read是我已知的想要连接的蓝牙设备读取数据的特征值。
(以上3个都是为了做比对,真实的操作按照获取到的sericeid, characterid为准)。
4、connectedDevice 是已连接了的设备信息对象。
init完成后开始调用连接 startConnect();
startConnect代码:
startConnect: function () { var that = this ; if (that.connectedDevice.state) return ; that.connectedDevice.deviceId = "" ; that.connectedDevice.state = false ; // 如果适配器已经初始化不在调用初始化(重复初始化会报错) if ( this .adapterHasInit == undefined || this .adapterHasInit) return ; wx.showLoading({ title: '初始化蓝牙' , duration: 2000 }); // 开启蓝牙适配器状态监听 this .listenAdapterStateChange(); // 初始化蓝牙适配器状态(必须步骤,否则无法进行后续的任何操作) wx.openBluetoothAdapter({ success: function (res) { console.log( "初始化蓝牙适配器成功" ); that.getBluetoothAdapterState(); that.adapterHasInit = true ; }, fail: function (err) { console.log(err); wx.showLoading({ title: '请开蓝牙' , icon: 'loading' , duration: 2000 }) } }); } |
在初始化蓝牙适配器状态成功后调用getBluetoothAdapterState()方法。
getBluetoothAdapterState代码:
getBluetoothAdapterState: function () { var that = this ; wx.getBluetoothAdapterState({ success: function (res) { console.log(res); var available = res.available; that.isDiscovering = res.discovering; if (!available) { wx.showLoading({ title: '请开蓝牙' , icon: 'loading' , duration: 2000 }) } else { if (!that.connectedDevice[ 'state' ]) { that.judegIfDiscovering(res.discovering); } } }, fail: function (err) { console.log(err); } }) } |
说明:此方法是用来获取当前蓝牙状态。
当检测到蓝牙可用时调用judegIfDiscovering方法。
judegIfDiscovering代码:
judegIfDiscovering: function (discovering) { var that = this ; if ( this .isConnectinng) return ; wx.getConnectedBluetoothDevices({ services: [that.serviceId], success: function (res) { console.log( "获取处于连接状态的设备" , res); var devices = res[ 'devices' ]; if (devices[0]) { if (that.isAndroidPlatform) { wx.showToast({ title: '蓝牙连接成功' , icon: 'success' , duration: 2000 }); } else { that.getConnectedBluetoothDevices(256); } } else { if (discovering) { wx.showLoading({ title: '蓝牙搜索中' }) } else { if (that.isAndroidPlatform) { that.startBluetoothDevicesDiscovery(); } else { that.getConnectedBluetoothDevices(267); } } } }, fail: function (err) { console.log( 'getConnectedBluetoothDevices err 264' , err); if (that.isAndroidPlatform) { that.startBluetoothDevicesDiscovery(); } else { that.getConnectedBluetoothDevices(277); } } }); } |
说明:
1、此方法是用来判断是否正在扫描。
2、isAndroidPlatform 是通过小程序的getSystemInfo获取到的判断是安卓设备还是IOS设备。
如果是安卓设备调用startBluetoothDevicesDiscovery()开启扫描,如果是IOS设备调用getConnectedBluetoothDevices() 开启获取已配对的蓝牙设备。
作者:熊晨沣【极乐小程序社区(http://www.wxapp-union.com)博主】
原文:http://www.wxapp-union.com/thread-116-1-1.html
