PC端canvas2d,scale缩放后wx.canvasToTempFilePath生成图片不对?

Canvas2D,根据像素比使用scale缩放后,用wx.canvasToTempFilePath生成图片,在PC端会导致生成的图片不完整。请管理员大大指教!

canvas.width = canvasWidth*this.data.dpr

canvas.height = canvasHeight*this.data.dpr

ctx.scale(this.data.dpr, this.data.dpr) // 根据像素比放大

1.开发工具和手机端正确:能完整生成全图。

2.PC端同样代码,无法生成完整全图。

代码片段:https://developers.weixin.qq.com/s/IW9zr9mJ73Pj

主要代码:

const app = getApp()
const sysInfo = wx.getSystemInfoSync() // 获取设备信息

Page({
  data: {
    dpr: sysInfo.pixelRatio,
    canvasWidth: 750,
    canvasHeight: 421.875, // 默认16:9
    fileCoverHttpUrl: 'https://jszs.ds.net.cn/api/file7/ccw/temp/2023-07-24/1522147391/3e22c349259b2d9000b8d7c2d93d7314.mp4?ss=0.1',
  },
  onLoad() {

  },
  handleDraw() {
    const {fileCoverHttpUrl} = this.data;
    let imagePath = '';
    this.createCanvas().then(async () => {
      const coverImageInfo = await wx.getImageInfo({
        src: fileCoverHttpUrl,
      })
      const {path, width, height} = coverImageInfo;
      imagePath = path; // 临时路径
      this.loadImg(imagePath).then(img => {
        this.drawMedia(img);
      })
    });
  },
  drawMedia(media) {
    const {canvas, ctx} = this;
    const {canvasWidth, canvasHeight} = this.data;
    console.log('drawMedia', canvasWidth, canvasHeight);
    canvas.width = canvasWidth*this.data.dpr
    canvas.height = canvasHeight*this.data.dpr
    ctx.scale(this.data.dpr, this.data.dpr) // 根据像素比放大
    ctx.drawImage(media, 0, 0, canvasWidth, canvasHeight);
    // 延时生成图片
    setTimeout(() => {
      wx.canvasToTempFilePath({
        canvas: canvas,
        x: 0,
        y: 0,
        width: canvasWidth*this.data.dpr,
        height: canvasHeight*this.data.dpr,
        destWidth: canvasWidth, // 输出的图片的宽度
        destHeight: canvasHeight,
        success: res => {
          wx.hideLoading();
          this.setData({
            showPoster: true,
            tempShareImg: res.tempFilePath,
          });
        },
        fail: () => {
          wx.showToast({
            title: '图片生成失败~',
            icon: 'none'
          });
        }
      })
    }, 300)
  },

  createCanvas() {

    return new Promise(resolve => {
      wx.createSelectorQuery()
      .select('#canvas')
      .fields({ node: true, size: true })
      .exec((res) => {
        const {canvasWidth, canvasHeight} = this.data;
        const canvas = res[0].node;
        const ctx = canvas.getContext('2d');
        canvas.width = canvasWidth;
        canvas.height = canvasHeight;
        ctx.clearRect(0, 0, canvasWidth, canvasHeight)
        this.canvas = canvas;
        this.ctx = ctx;
        resolve();
      })
    })


  },
  loadImg(src){
    return new Promise((resolve, reject) => {
      const {canvas} = this;
      const image = canvas.createImage()
      image.src = src
      image.onload = () => {
        resolve(image)
      }
      image.onerror = () => {
        reject(new Error(`fail to fetch image form: ${src}`))
      }
    })
  },

})

最后一次编辑于  02-21
回答关注问题邀请回答
收藏

2 个回答

  • salex
    salex
    星期一 21:45

    如果canvas组件,设置了style.width、height, 需要保持和Canvas实例一样的值;导出尺寸要以Canvas实例尺寸除以桌面端pixelRatio重新计算

    const dpr = wx.getSystemInfoSync().pixelRatio;

    wx.canvasToTempFilePath({width: canvas.width / dpr, height: canvas.height / dpr})

    你上面的代码,试一下给canvas元素设置个width和height, 必须和canvas实例一样,MAC和PC就正常了

    星期一 21:45
    有用
    回复
  • 梁萧
    梁萧
    09-14

    你好,遇到同样的问题,有解决方案了吗

    09-14
